M-SERIES
EPSOLUTION

EPSILON forwarder cranes – with or without tilt mechanisms – feature the winning combination of a perfect finish, protected hoses and excellent workmanship.

Long reaches alongside an array of different boom systems make EPSILON a favourite among all OEMs. Another feature of EPSILON is EPSLIGHT. The latest LED technology is controlled via an elbow lever system to ensure that the light is always shining on the working area.

The M-Series is the medium-duty class of EPSILON cranes in the forwarder model range and covers lifting capacities of 7 to 8 tonne metres.

EPSILON-M70F | © PALFINGER-EPSILON

CONTROL METHODS

Available areas for

Technical details

M70F M80F
Telescopic boom length [dm] 80 81 86 101 80 81 86 101
Number of extensions 1 2 2 2 1 2 2 2
Net load moment [kNm] 68 71 68 65 78 82 78 75
Net slewing torque [kNm] 26 26 26 26 29 29 29 29
Slewing angle [°] 385 385 385 385 385 385 385 385
Max. reach [m] 8 8,1 8,6 10,1 8 8,1 8,6 10,1
Operating pressure [bar] 215 215 215 215 240 240 240 240
Max. pump capacity. 1K [l/min] 1x90 1x90 1x90 1x90 1x90 1x90 1x90 1x90
Max. pump capacity. 2K [l/min] - - - - - - - -
Max. pump capacity. 2K-LS [l/min] - - - - - - - -

Dead weight without joint/rotator

M70F M80F
Telescopic boom length [dm] 80 81 86 101 80 81 86 101
